High Efficiency Automatic Palletizer Machine with Film Wrapper Conveying Line for Carton Column Robot

High Efficiency Automatic Palletizer Machine with Film Wrapper Conveying Line for Carton Column Robot

Parameter
Related products

Parameter

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-2

GRANDEE MACHINE is located in Zhangjiagang City, near Shanghai China. We are expert in the field of liquid packaging machinery in the world. We have more than 10,000 square meters standard workshop, providing customers with a variety of product development, engineering design, consulting, technical services and other integrated EPC solutions.

Products Description

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-3

Automatic palletizer for aluminum can /glass bottle

The palletizer automatically and multi-layered stacks of packaged individual products such as cartons and film packages in a certain arrangement on pallets, and then pushes them to designated positions for easy transportation to the warehouse by forklifts. It can save labor, ensure the stable production of factory production lines, improve the production efficiency of production lines, and reduce the production costs of factories;

This equipment is controlled by imported brand (SIEMENS) PLC+ touch screen (Schneider), achieving intelligent operation and management. It is simple and easy to master, and multiple grouping forms are convenient to adjust. It can greatly reduce the labor force and lower the labor intensity, and improve the production line management level of enterprises. It is designed based on the concepts of high speed, smoothness and space-saving. Separate pallets are adopted, which are faster and more space-saving. One machine with multiple uses, quick adjustment, and suitable for palletizing products of various specifications

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-4

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-5

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-6

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-7

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-8

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-9

Main technical parameter

Name	Automatic palletizer
Capacity	≤50 boxes/min
Operation mode	Human-computer interface
Max.load per layer	260KG
Max. load capacity of the pallet	1600KG
Max. stacking height	1750mm
Voltage	380V/50Hz 3P
Power	10kw
Dimensions	8000×6000×3600mm
Weight	7500KG

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-10

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-11

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-12

Aluminum Can Filling Machine For Carbonated Drink / Beer

1. This can filling machine is suitable for filling beer and carbonated beverages. 2. The machine's driving force originates from the can sealer, equipped with variable frequency control for operators to adjust production speed. 3. All filling components can be lowered onto the cans, eliminating the need for can-lifting mechanisms; Cans remain on a single horizontal plane throughout the filling process without vertical movement. 4. Automatic shutdown features: Stops when inlet has cans but no lids; Stops when lid supply is insufficient. 5. Machine cannot start unless hand wheel positioning is confirmed. 6. Automatic shutdown triggered by can jams at the exit star wheel. 7. A proximity switch sensor on the in feed conveyor: Reduces machine speed and initiates shutdown when can supply is low; Gradually restores speed when can supply replenishes.

For more information, please feel free to contact us to send an inquiry!

Turnkey Solution

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-13

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-14

One stage or Second stage R.O. Water treatment system

Raw Water Tank→ Raw Water Pump→ Quartz Sand Filter→Activated Carbon Filter→ 5 Micron Filter→ 1 Micron Filter→High Pressure Pump→Primary Reverse Osmosis Device→Intermediate Water Tank→ Booster Pump→ (Secondary High Pressure Pump→Secondary Reverse Osmosis Device) → Ozone Mixer→Pure Water Pump→ Pure Water Tank→ External Supply Pump→ Titanium Tube Filter→ External Supply→ To Filling Machine

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-15

Automatic OPP BOPP hot melt Glue labeling machine

Automatic BOPP labeling machine is widely suitable for different material of containers and labels. The cost of each label is comparatively lower, it can meet the requirements of those users who have diverse kinds of the containers. It is one of the most economical models to make mass production and integrated operating. The equipment has massively used modularization design concept to make it easy and simple for users to change the bottles. Whether from the replacement of star wheel, guide plate or manual speed adjustment to automatic speed control, like changing the label is only needed to change the PLC program, the products concept that the equipment is used for users and considered for users is embodied in everywhere.

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-16

Automatic PVC PE Sleeve Shrink Labeling Machine

This fully automatic sleeve labeling machine is suitable for various kinds of bottles, like round bottles, square bottles, oval bottles, etc. This machine can automatically feed and cut film, and it can sleeve labels precisely, greatly saving labor and improving work efficiency. The machine can be widely used for beverage bottles, cosmetic bottles, shampoo bottles, etc.

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-17

Automatic Hot Glue Carton Packing Machine

The unpacked products or small packaging products automatically into the corrugated carton automation equipment, the working principle of the conveyor system will be products according to specifications, carton molding, products into the box, carton folding cover, box mouth sealing; Reduce the number of personnel and reduce the labor intensity of operators, improve the competitiveness of enterprises.

product high efficiency automatic palletizer machine with film wrapper conveying line for carton column robot-18

Robot Palletizer

Which contribute to the robotization of the palletizing system has a compact body and a high throughput. It is suitable for packing bottled drinking water, juice, carbonated soft drinks etc. with production capacity up to 520layer/h. Suitable robot models can be selected according to the work pieces. Payload 110kg,140kg, 185kg,315kg, 500kg, 700kg.

NO.	Item	Data
1	Power	15KW(will be changed according to different models)
2	Robot	KUKA,ABB,NACHI
3	Max load per pallet	1.6tons (will be changed according to different models)
4	Pallet size	1200x1000mm(can be customized according to customer requirements)
5	Palletizing speed	10-80packs/min(the palletizing speed is related to the size of the pallet and the grouping form of each layer)
6	Pallet material	wood or plastic
7	Overall size	(L)8000MMx(W)4500MMx(H)3000MM(will be changed according to different models)
8	Machine weight	4500KG(will be changed according to different models)
