Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service
Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service

Good Price Energy Save Automatic 4 Cavity PET Water Bottles Blow Molding Machine Support Overseas Service

Get a Quote
  • Parameter
  • Related products
Parameter
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-2
GRANDEE MACHINEis located in Zhangjiagang City, near Shanghai China. We are expert in the field of liquid packaging machinery in the world. We have more than 10,000 square meters standard workshop, providing customers with a variety of product development, engineering design, consulting, technical services and other integrated EPC solutions.
Products Description
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-3


Automatic 4 cavity bottle blowing machine for beverage filling line

✅ Smart Control – Intuitive HMI for effortless operation
✅ Automated Feeding – Automatic blank sorting & feeding with hopper storage
✅ Energy-Saving Heating – Uniform preform heating with adjustable temperature zones
✅ Zero Contamination – Closed-loop system guarantees hygienic production
✅Continuous Production: Engineered for non-stop operation with minimal maintenance requirements

Widely Used For: PET bottles for water, beverages, oils, cosmetics, and pharmaceuticals

Why GD-4000B Series?
→ Produce more with less energy
→ Fully servo-driven system ensures precise control
→ Stable operation with high output capacity

🎯 Boost your production efficiency – request a quote today!
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-4
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-5
Main feature:
1.Bottle preform fixture, automated conveying, and precise positioning of preforms, preparing for the blowing.
2.Infrared lamps precisely control heat distribution to ensure preforms can be uniformly blown by high-pressure air in subsequent blow molding processes.
3.Shapes bottle profiles with servo-pneumatic systems for precise mold control and automated blow molding
4.Multiple infrared heating elements (visible glowing modules) uniformly and precisely heat PET preforms.
5.Precisely positions and transfers PET preforms with stable orientation for efficient production flow
6.Coordinates molds, servo drives, and pneumatic systems to transform preforms into PET bottles
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-6
High pressure air compressor : Compress air,used for blowing bottle. ( Pressure 30bar )
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-7
Item/model
PET-2.4/30
Air discharge
2.4m3
Working pressure
30bar
Air tank volume
0
Motor power
15kw×2
Voltage
380V/50Hz or customized
Dimensions(L×W×H)
1900×1880×1260mm
Net weight
985kg
Low pressure air compressor : Used for blower action.( Pressure 10bar )
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-8
Item/model
PET-1.6/12.5
Air discharge
1.6m3
Working pressure
12.5bar
Air tank volume
300Ltr.
Motor power
15kw
Voltage
380V/50Hz or customized
Dimensions(L×W×H)
1800×900×1700mm
Net weight
600kg
High pressure air tank : Store high pressure air.( Pressure 30bar )
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-9
Item/model
PET-0.6/30
Air discharge
0.6m3
Working pressure
30bar
Air tank volume
600Liter
Dimensions(L×W×H)
2200×⌀650mm
Net weight
300kg
High pressure air dryer : Cooling and dry air,improve bottle quality,prolong pneumatic parts life.
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-10
Item/model
PET-2.6/30
Air discharge
2.6m3
Working pressure
30bar
Fan power
90w
Motor power
0.8kw
Voltage
220V/50Hz or customized
Dimensions(L×W×H)
680×550×620mm
Net weight
80kg
High pressure air filter : Including 1 set T-class filter (1um) and 1 set A-class filter (0.01um). Cleaning oil and dust.
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-11
Item/model
PET-2.5/30
Air discharge
2.5m3
Working pressure
30bar
Dimensions(L×W×H)
660×⌀350
Net weight
50kg
Cooling chiller : Cooling mould,make the machine suitable to working 24 hour per day
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-12
Item/model
PET-AC-05
Cooling capacity
12,800Kcal/hr.
Working water pressure
5bar
Max.flow rate of water
120Liter/Min.
Water tank volume
100Liter
Motor power
3.75kw
Voltage
380V/50Hz or customized
Dimensions(L×W×H)
1300×960×1100mm
Net weight
200kg
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-13
Technical Parameters

Unit
GD-4000B
GD-6000B
GD-7000B
GD-9000B





Host Machine Parameter
Capacity
B/H
4000BPH
6000-12000BPH
14000-15000BPH
18000BPH
Cavity
 cavities
4
6
7
9
Mold Route
 mm
120
110
110
110
Bottom Mold Route
mm
40-70mm
50
50
50

 Bottle Spacing
mm
114
114
114
80



Products parameter
 Max Capacity
ml
1500
1500
1500
600

 Max Bottle Boby Heigh
mm
300
330
330
260

Max Bottle Body Diamete
mm
76
105
105
68



Electrical Parameter
Heating Oven Quantity
PCS
4*4
4*4
4*4
4*4

Heating Lamp Quantity

PCS
9
9
9
7
Total Power Capacity
KW
56
92
92
100


Air Source Parameter
 Working Pressure
MPA
0.7-0.9
0.7-0.9
0.7-0.9
0.7-0.9

 Blowing Pressure
MPA
2.0-3.0
2.5-3.0
2.5-3.0
2.5-3.0

Air Capacity Consumption
m³/min
2/30
10/30
10/30
12/30


Cooling Chiller Parameter
Temperature
℃
9-13
9-13
9-13
9-13

Pressure
 MPA
0.4
0.4
0.4
0.4

Rated Power
HP
3
3
3
5


Dimension
Host Machine Size
 MM
2500*1850*2100
5200*2200*2400
5200*2200*2400
5200*2200*2400

 Weight
T
2.5
5.5
6
6.5

For more information, please feel free to contact us to send an inquiry!

Turnkey Solution
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-14
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-15
Juice filling machine
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-16
Carbonated drink filling machine
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-17
Small bottle water filling machine
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-18
Automatic OPP BOPP hot melt Glue labeling machine
Automatic BOPP labeling machine is widely suitable for different material of containers and labels. The cost of each label is comparatively lower, it can meet the requirements of those users who have diverse kinds of the containers. It is one of the most economical models to make mass production and integrated operating.

product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-19
Operating Principle Of Packaging Machine
Automatic BOPP labeling machine is widely suitable for different material of containers and labels. The cost of each label is comparatively lower, it can meet the requirements of those users who have diverse kinds of the containers. It is one of the most economical models to make mass production and integrated operating.

Exhibition
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-20
Customer Acceptance Report
product good price energy save automatic 4 cavity pet water bottles blow molding machine support overseas service-21
FAQ
Q1: How to find suitable machine or complete beverage production line?
A1: Looking for beverage filling machine in www.grandeemachine.en.alibaba.com
•Enquiry: Contact us by email, phone call, fax, Instant Messenger (Trade manager, Skype, WhatsApp, Wechat) and let us know your requirements
• Discussion: Specify the items and what are you exactly looking for.

Q2: Are you a trading company or a manufactory?
A2: We are the manufacture of water/beverage filling machine and water treatment system over 10 years. We just not only sell drinking water machines and other related equipment, Quality is our culture. We have rich experienced engineers with technicians working team , providing good and after-sales service term , professional salesman terms .

Q3: Do you have technical support after we purchased your machines?
A3: We will arrange our professional technical to go aboard to your factory, they will help you and teach you how to install and maintenance the machines which you purchased. Or help you to fix machine when it has problems.

Q4: If you buy our machines, can you offer us wear-out spare parts?
A4: We provide our high quality machine 2 years guarantee , and we will also offer you 2 years wear-out spare parts for free. Once your machines broken or doesn't work within 2 years and you can't solve it, firstly, we will try to help you to find problems from your words description by phone or other communication tolls. Secondly, if the phone solutions still not work, our engineers will go to your factory to solve it. Meanwhile, they will teach you the related experiences for fixing.

For more information, please feel free to contact us to send inquiries!
