Intelligent Sensor Controlled Electronic Quantitative Liquor Wine Bottle Washing Filling and Sealing Machine

Intelligent Sensor Controlled Electronic Quantitative Liquor Wine Bottle Washing Filling and Sealing Machine

Spu:

1601681278632

Parameter
Related products

Parameter

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -2

GRANDEE MACHINE is located in Zhangjiagang City, near Shanghai China. We are expert in the field of liquid packaging machinery in the world. We have more than 10,000 square meters standard workshop, providing customers with a variety of product development, engineering design, consulting, technical services and other integrated EPC solutions.

Products Description

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -3

Automatic Quantitative Liquor filler Sealer with Smart Sensor

Engineered for premium and specialty spirits, our Weighing-Based Filling System delivers exact, consistent fills—bottle after bottle. Whether you produce rich health wines, high-end opaque-bottle liquors, or viscous craft spirits.

✔️ Accurate Dosing – Advanced weighing technology guarantees consistent volume, minimizing waste

✔️Built-In Quality Control – Automatic inspection ensures every bottle meets your standard

✔️ Easy to Clean, Ready to Run– Smooth surfaces and accessible design reduce downtime

✔️ No Splashing or Dripping–Damping flow channel prevents foaming. Reverse-seal valve cuts off drip-free

➤Get your custom filling solution — send us for a quote!

3D model diagram:

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -4

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -5

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -6

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -7

SUS Pipe Intelligent Sensor-Based Electronic Liquor Filling Machine

The filling section is made of stainless steel, not require rinsing. Suitable for clear spirits, offering hygiene and corrosion resistance.The head tank features a specially designed bottom structure to ensure smooth outflow of wine.A high-precision floating ball level sensor maintains stable liquid level in the supply tank, ensuring consistent operation.

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -8

Liquid Level Gauge Glass Tube Smart Electronic Dosing Filler Sealer

The filling section is made of glass, suitable for colored or opaque wine, ensuring visual clarity and compatibility.These types of liquor require rinsing to ensure the absence of any liquid residue.

Besides, we still have Quantitative / Volumetric and Weighing Filling Sealing Machine.

Choose the right system to enhance your product integrity and filling performance

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -9

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -10

Capping part

Place and capping system, use Germany Zalkin aluminum screw cap technology,make sure minimum bottle crash during capping.Capping effect is stable and reliable,Defective rate ≤0.2%

The design has no hard-to-clean corners, The interior is polished, and inspection windows are installed at the top, eliminating,cleaning blind spotsmeeting the hygiene standards for wine filling and simplifying the manual cleaning process.

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -11

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -12

Model

GD-18-6

GD-24-8

GD-32-8

GD-36-10

GD-48-12

GD-60-15

GD-72-18

Bottle Adaptation

Bottle Height

115mm≤H≤300mm

110mm≤H≤300mm

Bottle Diameter

φ50mm～φ100mm

Bottle Type

Square, Flat, Tapered Bottles, etc.

Capacity

(50Oml/BPH)

3300--5500

4200-7000

5800-9600

6600-11000

8500--15000

11000--18000

13000-22000

Power(kW)

0.75

1.5

2.2

3+0.75

5.5+0.55

Machine Weight (T)

1.8

2.2

Overall Dimensions

(mm)

2000×1600×2400

2100×1900×2400

2200×2300×2600

2500×2510×2600

2800×3200×2800

3300×3500×2800

4280*3850*2800

Filling Accuracy

±1.5ml/500ml

Filling Range

40ml～750ml

Air Pressure Range

0.4~0.5Mpa

Conveyor

Height from Ground

Standard Line: 900–950 mm / Raised Line: 1000–1050 mm

For more information, please feel free to contact us tosend an inquiry!

Turnkey Solution

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -13

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -14

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -15

Automatic Palletizer for Beverage Cartons

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -16

Automatic depalletizer for glass bottle

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -17

Automatic glass bottle washer and dryer machine

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -18

Automatic Rotary Full Servo Electronic CAM Three Labels Station Sticky Labeling Machine

The rotary continuous operation design, paired with low-inertia high-speed servo motors, delivers a labeling speed of up to 60 meters per minute, with a single machine capacity reaching a maximum of 24,000 bottles per hour. It can seamlessly integrate with high-speed filling lines, boasting an efficiency 10 to 15 times that of manual labeling. The equipment supports 24/7 continuous operation without the limitations of human fatigue. Additionally, features such as automatic label splicing and label shortage alarms reduce downtime losses, significantly improving the overall throughput of the production line.

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -19

Automatic Hot Glue Carton Packing Machine

The unpacked products or small packaging products automatically into the corrugated carton automation equipment, the working principle of the conveyor system will be products according to specifications, carton molding, products into the box, carton folding cover, box mouth sealing; Reduce the number of personnel and reduce the labor intensity of operators, improve the competitiveness of enterprises.

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -20

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -21

Customer Acceptance Report

intelligent sensor controlled electronic quantitative liquor wine bottle washing filling and sealing machine -22

FAQ

Q1: How to find suitable machine or complete beverage production line?
A1: Looking for beverage filling machine in www.grandeemachine.en.alibaba.com
•Enquiry: Contact us by email, phone call, fax, Instant Messenger (Trade manager, Skype, WhatsApp, Wechat) and let us know your requirements
• Discussion: Specify the items and what are you exactly looking for.

Q2: Are you a trading company or a manufactory?
A2: We are the manufacture of water/beverage filling machine and water treatment system over 10 years. We just not only sell drinking water machines and other related equipment, Quality is our culture. We have rich experienced engineers with technicians working team , providing good and after-sales service term , professional salesman terms .

Q3: Do you have technical support after we purchased your machines?
A3: We will arrange our professional technical to go aboard to your factory, they will help you and teach you how to install and maintenance the machines which you purchased. Or help you to fix machine when it has problems.

Q4: If you buy our machines, can you offer us wear-out spare parts?
A4: We provide our high quality machine 2 years guarantee , and we will also offer you 2 years wear-out spare parts for free. Once your machines broken or doesn't work within 2 years and you can't solve it, firstly, we will try to help you to find problems from your words description by phone or other communication tolls. Secondly, if the phone solutions still not work, our engineers will go to your factory to solve it. Meanwhile, they will teach you the related experiences for fixing.

For more information, please feel free to contact us to send inquiries!
