Automatic 24 36 Cavity Compression Molding Machine for Plastic Bottle Caps 28mm 38mm PE PP Cap Making Machine

Automatic 24 36 Cavity Compression Molding Machine for Plastic Bottle Caps 28mm 38mm PE PP Cap Making Machine

Spu:

1601719687234

Parameter
Related products

Parameter

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-2

GRANDEE MACHINEis located in Zhangjiagang City, near Shanghai China. We are expert in the field of liquid packaging machinery in the world. We have more than 10,000 square meters standard workshop, providing customers with a variety of product development, engineering design, consulting, technical services and other integrated EPC solutions.

Products Description

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-3

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-4

Automatic 24 cavity Compression Molding Machine for Plastic Caps

This advanced machine produces soda and mineral water bottle caps from granular plastic. Raw material is automatically fed, plasticized at high temperature, then extruded and cut into precise portions. These portions are distributed into mold cavities and formed under high pressure, ensuring consistent shape, strength, and sealing performance.

Why This Matters to Beverage Industry Clients:
✅ High Precision – Ensures every cap meets strict quality standards for leak-proof sealing.
✅ Fully Automated – Reduces labor costs and increases production efficiency.
✅ Customizable Mold – Adaptable to various cap sizes and styles for different beverage applications.
✅ Energy-Efficient & Stable Operation – Designed for continuous, reliable production in high-demand environments.

Ideal for mineral water, soda, juice, and other beverage bottle cap production lines. Contact ustoday to learn how our machine can optimize your capping process!

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-5

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-6

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-7

Mold Cavity & Core Assembly

This is the core molding section of a rotary compression cap molding machine, specifically the upper core (male mold) and lower cavity (female mold) assembly for plastic bottle caps.

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-8

Rotary Pneumatic Demolding & Clamping Unit

Each connected to blue/orange pneumatic hoses.The pneumatic system controls mold opening/clamping and ejects finished caps via air pressure after forming and cooling.This design enables high-speed, continuous production of plastic bottle caps.

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-9

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-10

Hopper Dryer and Hydraulic Power

1. Hopper Dryer – For high-speed cap molding machines, ensuring continuous, dry material feeding.

2. Hydraulic Power – Split-type hydraulic station design – ensures the motor stays cool even after prolonged operation.
· Full YUKEN pump heads and directional valves – delivering reliable quality and strong stability.
· Nitrogen pressure stabilization device – ensures consistent pressing force across every cylinder, resulting in stable cap forming.
· Inverted motor with oil pump housed inside the tank – significantly reduces operating noise.
· Clean-out window design – makes hydraulic oil changes and cleaning more convenient.
· Dual-pump high/low pressure design – ensures stable high-speed cap forming.

Servo Control System

High performance servo system ensures precise, synchronized control for all processes. Smart diagnostics adapt to different materials, boosting efficiency and yield..

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-11

Electrical Control Cabinet

This cabinet enables precise, reliable control of the entire production process, supporting high-speed, continuous operation while ensuring safety and ease of maintenance.

Automatic Cap Cooler Machine, Cap Slitting and Folding Machine

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-12

Machine model	GRD-ZG-0024
Capacity	36000-48000PCS/H
Cap Diameter	20-60mm
Cap Height	10-30mm
Cap material	PP/PE
Extruder Heater Ring Power	25KW
Extruder Motor Power	15KW
Mold Cavity	24 cavities
Molding Machine Installed Motor Power	2.2KW
Hydraulic Power Unit	35kw
Chiller Power	7.5kw
Air Consumption	0.5m³/h 1.2Mpa
Power	380V，50Hz or customized
Machine size	400017002400mm
Machine weight	7000kg

For more information, please feel free to contact us to send an inquiry!

Turnkey Solution

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-13

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-14

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-15

Juice filling machine

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-16

carbonated filling machine

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-17

water filling machine

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-18

Automatic 4 Cavity Bottle Blowing Machine

GD series fully automatic bottle blowing machines are developed with leading global technology, featuring intelligent operation, stable performance, and efficient production with low energy consumption. Designed to prevent intermediate contamination, they are ideal for producing containers for food, beverages.

automatic 24 36 cavity compression molding machine for plastic bottle caps 28mm 38mm pe pp cap making machine-19

Automatic Linear High Speed Shrink Packing Machine

The linear PE film packing machine offers smart, reliable operation through PLC and touch screen control, delivering consistent high-quality wraps with a pneumatic sealing and cutting system, while the rapid cooling system instantly locks the shape and the buffer rack ensures continuous flow with zero downtime
